The MIL-DTL-26482 Series Ⅰ connector has a current rating of 7.5 A, making it suitable for a wide range of power and signal applications. It is a jam nut receptacle, which means it is a threaded connector that is used to secure a mating plug or connector. The jam nut receptacle is designed to be mounted on a panel or bulkhead and is secured in place using a threaded nut.
The MIL-DTL-26482 Series Ⅰ connector has a shell size of 08, which means it has a diameter of approximately 0.5 inches. This makes it a compact and versatile connector that can be used in a variety of applications. The shell size is an important consideration when selecting a connector, as it determines the size of the connector and the number of contacts that can be accommodated.
The MIL-DTL-26482 Series Ⅰ connector is part of the MIL-DTL-26482 family of connectors, which are widely used in military and aerospace applications. These connectors are built to strict military specifications and are designed to withstand harsh environments and extreme temperatures. The MIL-DTL-26482 Series Ⅰ connector is highly reliable and is designed to provide long-lasting performance in the most demanding applications.
In conclusion, the MIL-DTL-26482 Series Ⅰ connector is a high-performance, miniature connector that is ideal for use in military and aerospace applications. It has a current rating of 7.5 A, a shell size of 08, and is a jam nut receptacle. It is built to strict military specifications and is highly reliable in extreme environments. The MIL-DTL-26482 Series Ⅰ connector is part of the MIL-DTL-26482 family of connectors, which are widely used in military and aerospace applications. If you need a miniature connector that is reliable and built to exacting standards, the MIL-DTL-26482 Series Ⅰ connector is an excellent choice.
| Product Name | MIL-DTL-26482 Series I |
| Gender | Jam Nut Receptacle |
| Number of Contacts | 4 |
| Contact Termination | Solder |
| Shell Material | Aluminum Alloy |
| Voltage Rating | 500V |
| Current Rating | 7.5 A |
| Shell Size | 08 |
| Coupling Nut Material | Aluminum Alloy |
| Shell Finish | Olive Green Cadmium |
The aluminum alloy shell material and coupling nut material make it lightweight yet strong enough to withstand impact and vibration. This connector is designed for solder contact termination, which ensures a secure and stable connection between devices.
The MIL-DTL-26482 Series 1 product is commonly used in military and aerospace applications. It is also suitable for use in industrial and commercial environments where high reliability and durability are required. The miniature size of the connector makes it ideal for applications where space is limited.
The MS3114M8-4SN model is manufactured in China to ensure consistent quality and cost-effectiveness. It has been rigorously tested and certified to meet or exceed the standards set by the military and aerospace industries.
Some of the typical applications of the MS3114M8-4SN connector include avionics, missiles, radars, and communication systems. It can also be used in medical equipment, industrial machinery, and transportation systems.
Overall, the KAIDA MS3114M8-4SN connector is a highly reliable and durable product that can be used in a wide range of industries and applications. Its miniature size, hermetic backshell, and jam nut receptacle make it a popular choice for military, aerospace, and commercial applications where high performance and reliability are essential.
The MIL-DTL-26482 Series 1 is a circular connector product that offers a wide range of technical support and services, including:
Our technical support team is available to assist with any questions or issues related to the MIL-DTL-26482 Series 1 product, ensuring that our customers receive the highest level of service and support.
Product Packaging:
Shipping:
Q: What is the brand name of this product?
A: The brand name of this product is KAIDA.
Q: What is the model number of this product?
A: The model number of this product is MS3114M8-4SN.
Q: Where is this product manufactured?
A: This product is manufactured in China.
Q: What is the MIL-DTL-26482 Series 1 product?
A: The MIL-DTL-26482 Series 1 product is a circular electrical connector that meets military specifications for ruggedness and durability.
Q: What is the purpose of this product?
A: This product is used for connecting electrical wires in harsh environments that require high levels of reliability and durability, such as military and aerospace applications.
