With a voltage rating of 500V, these Micro-D connectors offer a high level of electrical performance and can safely handle a wide range of power requirements. Additionally, the gold over nickel contact plating ensures excellent conductivity and corrosion resistance, further enhancing their longevity and reliability.
These connectors are designed for vertical mount printed circuit board applications, making them an ideal choice for electronics manufacturers and designers. They feature a compact form factor that allows for high-density packaging, while their aluminium shell material provides superior strength and durability.
With a rating of 500 mating cycles, these Micro-D connectors are built to last. They can withstand repeated use and are designed to maintain their performance over time, ensuring that your electronic systems remain reliable and efficient.
In summary, the MIL-DTL-83513 Micro-D Connectors are a high-quality, reliable solution for your electronic connectivity needs. With their high voltage rating, gold over nickel contact plating, vertical mount printed circuit board design, aluminium shell material, and 500 mating cycle rating, these connectors are an excellent choice for electronics manufacturers and designers alike.
| Product Attribute | Value |
| Product Name | MIL-DTL-83513 Micro-D Connectors |
| Part Number | GMR7580-9S2BPN |
| Connector Type | Vertical Mount Printed Circuit Board Connectors |
| Gender | Rectangular Receptacle |
| Number of Contacts | 9 |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
| Shell Material | Aluminium |
| Voltage Rating | 500V |
| Operating Temperature | -55 To +125°C |
| Mating Cycles | 500 |
The GMR7580-9S2BPN Micro-D Vertical Mount Connector is designed for use in a range of scenarios, including military, aerospace, and industrial applications. These connectors are commonly used in harsh environments where reliable and high-performance connectors are needed. They are suitable for use in applications such as equipment used in the oil and gas industry, military aircraft, and communication equipment.
The KAIDA Micro-D Vertical Mount Connector is also commonly used in medical equipment, test and measurement equipment, and robotics. These connectors are suitable for use in devices such as ultrasounds, X-ray machines, CAT scanners, and other medical devices. In the field of robotics, the connector is used in devices such as robotic arms, servo motors, and control systems.
The GMR7580-9S2BPN Micro-D Vertical Mount Connector is also suitable for use in the automotive industry. The connector's high-performance features make it a popular choice for use in electronic control units, anti-lock brake systems, and other automotive applications.
In conclusion, the KAIDA GMR7580-9S2BPN Micro-D Vertical Mount Connector is a versatile and reliable connector that is suitable for various industrial applications. Its high-performance features, including its voltage rating, number of contacts, and operating temperature range, make it a popular choice for use in harsh environments. The connector's reliability and durability make it a valuable asset in various applications, including military, aerospace, medical, automotive, and robotics.
KAIDA offers product customization services for the GMR7580-9S2BPN Micro-D Connectors, a 9 pin rectangular connector designed for vertical mount printed circuit boards. These connectors are made from high-quality aluminum materials and have a voltage rating of 500V. They are ideal for applications that require reliable and compact connectors. Our Micro-D connectors are made in China and can operate in temperatures ranging from -55 to +125°C. We can customize the connectors to suit your specific needs, ensuring that they meet your exact requirements and specifications. Choose KAIDA for all your Micro-D connector needs.
The MIL-DTL-83513 Micro-D Connectors product offers technical support and services for:
Our team of experts is dedicated to providing exceptional service and support throughout the product lifecycle.
Product Packaging:
Shipping:
A: The brand name of the Micro-D Connectors product is KAIDA.
2. Q: What is the model number of the Micro-D Connectors product?A: The model number of the Micro-D Connectors product is GMR7580-9S2BPN.
3. Q: Where is the Micro-D Connectors product manufactured?A: The Micro-D Connectors product is manufactured in China.
4. Q: What is the temperature range of the KAIDA Micro-D Connectors product?A: The KAIDA Micro-D Connectors product has a temperature range of -55°C to +125°C.
5. Q: What is the contact arrangement of the GMR7580-9S2BPN Micro-D Connectors product?A: The GMR7580-9S2BPN Micro-D Connectors product has a contact arrangement of 9S2BPN.
