Gold Over Nickel Contact Plating Metal Shell Part Number CDBF 25T 15CM Robust Protective Case Designed for Industrial Electronics

Product Description:

The MIL-DTL-83513 Micro-D Connectors are precision-engineered electrical connectors designed to meet the rigorous demands of many applications. Known for their reliability and compact design, these connectors provide a robust solution for secure and efficient electrical connections in environments where performance and durability are critical. With a current rating of 3 A and a voltage rating of 600V, these connectors are capable of handling moderate power loads while maintaining excellent electrical integrity.

One of the standout features of the MIL-DTL-83513 Micro-D Connectors is their adherence to the stringent MIL Spec CDbF Electrical Connector standards. This certification ensures that every connector meets high-quality benchmarks for durability, environmental resistance, and electrical performance. The connectors are specifically designed to operate reliably under harsh conditions, including vibration, shock, and extreme temperatures, making them ideal for use in demanding applications.

The connectors are constructed with a plastic shell that offers both lightweight and robust protection for the internal components. The plastic shell not only reduces the overall weight of the connector, which is a critical factor in aerospace and portable electronic systems, but also provides excellent resistance to corrosion and environmental damage. This dual benefit ensures long-lasting performance even in challenging operational environments.

Featuring 25 pins, these Micro-D connectors provide a versatile interface for multiple signal and power connections within a compact footprint. The 25-pin configuration allows for efficient wiring and organization, supporting complex circuitry without the bulk of larger connectors. This pin count is particularly advantageous for applications requiring multiple signal paths in confined spaces, offering engineers a flexible and reliable connection solution.

The contact material used in these connectors is a high-quality copper alloy, chosen for its excellent conductivity and mechanical strength. Copper alloy contacts ensure minimal signal loss and reliable electrical performance over time. To further enhance durability and signal integrity, the contacts are plated with gold over nickel. Gold plating provides superior resistance to corrosion and oxidation, ensuring consistent, low-resistance contacts even after repeated mating cycles. The nickel underlayer adds mechanical strength and prevents the diffusion of base metals, maintaining the integrity of the contact surfaces.

Designed for easy assembly and maintenance, the MIL-DTL-83513 Micro-D Connectors feature precise alignment and secure locking mechanisms that prevent accidental disconnection. The connectors are engineered to provide reliable mating cycles, ensuring that connections remain stable throughout the lifecycle of the equipment. This makes them an excellent choice for mission-critical systems where connector failure is not an option.

In summary, the MIL-DTL-83513 Micro-D Connectors combine a compact 25-pin layout with the robustness of a plastic shell and the superior electrical characteristics of gold-over-nickel plated copper alloy contacts. Rated for 3 A current and 600V voltage, these connectors meet the MIL Spec CDbF Electrical Connector standards, making them a trusted component in the design of high-performance electrical systems. Their durable construction, reliable electrical performance, and space-saving design make them an essential choice for engineers seeking dependable, high-quality interconnect solutions.

Features:

• Product Name: MIL-DTL-83513 Micro-D Connectors
• Operating Temperature Range: -55 to +125°C
• Voltage Rating: 600V
• Contact Plating: Gold Over Nickel for enhanced conductivity and corrosion resistance
• MIL Specification: CDbF Electrical Connector compliant
• Mating Cycles: 500 cycles for reliable repeated connections
• Connector Shell: Durable Plastic Shell for lightweight and robust protection
• Connector Type: Male Plug equipped with Pin contacts
• Model Reference: CDBF-25T-15CM

Technical Parameters:

Applications:

The KAIDA CDbF Series Micro-Rectangular Connectors, specifically the model CDBF-25T-15CM, are designed to meet the rigorous demands of various high-performance applications. Originating from China, these MIL-DTL-83513 Micro-D Connectors offer exceptional reliability and durability, making them ideal for use in many environments. Featuring a robust plastic shell, these connectors provide excellent insulation and protection against environmental factors, ensuring stable connections in challenging conditions.

These connectors are widely used in aerospace and defense systems where compact yet highly reliable connectors are critical. The CDbF Series Micro-Rectangular Connectors, with their gold-over-nickel plated copper alloy contacts, guarantee superior conductivity and corrosion resistance. This makes them suitable for avionics,  communication equipment, and navigation systems, where maintaining signal integrity is paramount. Their ability to endure up to 500 mating cycles ensures longevity and repeatable performance in applications requiring frequent connection and disconnection.

In addition to aerospace and defense, the CDBF-25T-15CM connectors are also popular in industrial automation and instrumentation scenarios. The plastic shell design not only reduces weight but also offers resistance to mechanical stress, making these connectors ideal for use in robotic systems, sensor interfaces, and control panels. With a voltage rating of 600V and a current rating of 3A, these connectors can handle moderate power requirements, allowing them to be deployed in various electronic control and monitoring devices.

Medical devices and telecommunications equipment also benefit from the compact size and reliable performance of KAIDA’s CDbF Series Micro-Rectangular Connectors. Their small footprint and secure locking mechanism make them perfect for handheld devices and portable communication tools. Furthermore, the plastic shell construction enhances user safety and connector durability in everyday operational scenarios.

Overall, the KAIDA CDBF-25T-15CM Micro-D Connector with a plastic shell is an excellent choice for applications requiring a combination of compactness, durability, and reliable electrical performance. Whether in harsh environments, precise industrial automation, or sensitive medical equipment, these connectors deliver consistent and dependable connectivity solutions.

Customization:

KAIDA offers product customization services for the MIL-DTL-83513 Micro-D Connectors, specifically the CDBF-25T-15CM model. This connector features a durable Plastic Shell and is part of the CDbF Series Micro-Rectangular Connectors, designed to meet stringent MIL specifications. With 25 pins and a current rating of 3 A, it ensures reliable electrical performance for demanding applications. The connector utilizes high-quality copper alloy contact material, providing excellent conductivity and durability for up to 500 mating cycles. Manufactured in China, the KAIDA CDBF-25T-15CM is ideal for customers requiring robust, customizable Micro-D connector solutions with precise specifications.

Support and Services:

Product Technical Support and Services for MIL-DTL-83513 Micro-D Connectors include comprehensive assistance to ensure optimal performance and reliability. Our support team is available to provide detailed product information, application guidance, and troubleshooting assistance. We offer custom design solutions, engineering support, and technical documentation to meet specific project requirements. Additionally, our services encompass connector assembly instructions, inspection criteria, and maintenance recommendations to extend the lifecycle of your Micro-D connectors. We are committed to delivering prompt and effective support to help you achieve seamless integration and operation of MIL-DTL-83513 connectors in your systems.

Packing and Shipping:

Product Packaging and Shipping for MIL-DTL-83513 Micro-D Connectors are designed to ensure the highest level of protection and reliability during transit. Each connector is individually packaged in anti-static, moisture-resistant bags to prevent contamination and damage. The connectors are then securely placed in custom foam inserts or cushioned containers that provide shock absorption and prevent movement within the packaging.

The packaging materials comply with industry standards for environmental safety and are clearly labeled with part numbers, batch codes, and handling instructions. For bulk orders, connectors are organized in trays or reels, depending on the configuration, to facilitate easy handling and inventory management.

Shipping is carried out using trusted carriers with tracking capabilities to ensure timely delivery and traceability. All shipments include detailed packing lists and certificates of conformity as required by MIL-DTL-83513 specifications. Special handling requests can be accommodated upon customer request to meet specific logistical or environmental conditions.
