Jam Nut Receptacle Connector MIL DTL 38999 Series Ⅲ 13 Contacts Circular Connector Aerospace Standards.D38999/24WB35SA.TV07RW11-35SA,8D7-11W35SA

Part number:D38999/24WB35SA

Product Description:

The Military Detail-38999 Series Ⅲ connector is a robust and reliable solution designed to meet the stringent demands of military and aerospace applications. Known for its exceptional performance and durability, the MIL-DTL-38999 Series Ⅲ connectors are engineered to provide superior electrical and mechanical connections in harsh environments. This connector series stands out due to its advanced design features, making it a preferred choice for systems requiring high reliability and resistance to extreme conditions.

One of the key technical specifications of the Military Detailed-38999 Series Ⅲ connector is its current rating of 7.5 amperes. This rating ensures that the connector can handle moderate electrical loads efficiently without compromising safety or performance. The connector’s ability to maintain stable electrical conductivity under high current conditions is partly due to the high-quality copper alloy used in its contact material. Copper alloy contacts offer excellent conductivity along with resistance to corrosion and wear, ensuring long-term reliability and minimal signal loss.

Voltage rating is another critical attribute of the MIL-DTL-38999 Series Ⅲ connectors, with this product capable of withstanding voltages up to 500 volts. This high voltage rating makes it suitable for various military and aerospace electrical systems, where maintaining signal integrity and insulation under high voltage conditions is essential. The connector’s design ensures that it can handle these voltage levels safely, preventing electrical breakdowns and ensuring the protection of connected equipment.

The shell size of this MIL-DTL-38999 Series Ⅲ connector is 11, a dimension that strikes a balance between compactness and the capability to accommodate multiple contacts. The shell size directly influences the connector’s form factor, mounting options, and overall compatibility with existing equipment. Size 11 connectors are widely used in applications where space constraints are a consideration but where robust electrical performance cannot be compromised.

In addition to its electrical characteristics, the Military Detailed-38999 Series Ⅲ connector features a shell finished with olive green cadmium plating. This shell finish offers excellent corrosion resistance and environmental protection, which is crucial for connectors exposed to moisture, salt spray, and other challenging conditions commonly encountered in military environments. The olive green cadmium finish not only enhances the connector’s durability but also provides a distinctive appearance that aligns with military equipment standards.

The MIL-DTL-38999 Series Ⅲ connectors are designed with advanced coupling mechanisms that provide secure mating and unmating under vibration and shock conditions. This ensures that connections remain intact during the most demanding operational scenarios, such as in aircraft, ground vehicles, and naval vessels. The connector’s rugged construction, combined with its high-performance materials, makes it an ideal choice for mission-critical applications where connector failure is not an option.

Furthermore, the Military Detail-38999 Series Ⅲ connectors are engineered for ease of installation and maintenance. Their standardized design facilitates compatibility with a wide range of accessories and mounting hardware, allowing for flexible system integration. The connectors also comply with stringent military specifications, ensuring that they meet or exceed industry standards for performance, reliability, and quality control.

Overall, the MIL-DTL-38999 Series Ⅲ connector with a 7.5 A current rating, copper alloy contacts, olive green cadmium shell finish, 500V voltage rating, and shell size 11 represents a high-quality, dependable choice for military and aerospace electrical interconnections. Its combination of electrical performance, mechanical robustness, and environmental resistance makes it a trusted component in complex and demanding systems. Whether used in communication devices, avionics, or other critical military hardware, this connector series continues to uphold the rigorous standards required by modern defense applications.

Features:

• Product Name: MIL-DTL-38999 Series 3
• Also known as 8D Series, Military Detail 38999 Series Ⅲ, Detail-38999 Series Ⅲ
• Shell Material: Aluminum
• Contact Material: Copper Alloy
• Contact Type: Crimp
• Shell Size: 11
• Operating Temperature Range: -55°C to +125°C

Technical Parameters:

Applications:

The KAIDA MIL-DTL-38999 Series 3 connector, model number D38999/24WB35SA, is a highly reliable and robust connector designed for demanding applications. Originating from China, this connector features a jam nut receptacle type with a threaded coupling mechanism, ensuring secure and stable connections in critical environments. It incorporates 13 copper alloy crimp contacts, which provide excellent conductivity and mechanical strength, making it ideal for military and aerospace use.

The Military-Detailed-38999 Series Ⅲ connectors are widely used in scenarios where durability, performance, and resistance to harsh conditions are paramount. These connectors are perfectly suited for military vehicles, aircraft, and ground communication systems, where reliable electrical connections are essential to mission success. Their rugged design enables them to withstand vibration, shock, moisture, and extreme temperatures, which are common challenges in military operations.

In addition to military applications, Detailed-38999 Series Ⅲ connectors find extensive use in aerospace and industrial sectors. They are commonly implemented in avionics systems, radar equipment, and navigation systems, where high-density contact arrangements and secure coupling are critical. The crimp contact type ensures a stable and secure electrical connection, reducing the risk of signal loss or failure in critical systems.

The Military-Detail-38999 Series Ⅲ connectors also serve well in harsh industrial environments such as oil and gas exploration, rail transportation, and heavy machinery, where exposure to dust, moisture, and mechanical stress is frequent. Their robust design and reliable performance make them suitable for outdoor installations and mobile equipment that require dependable connectivity under strenuous conditions.

Overall, the KAIDA D38999/24WB35SA connector combines the advanced features of the Military-Detailed-38999 Series Ⅲ with precise manufacturing standards from China, delivering a product that excels in functionality and durability. Its 13-contact copper alloy crimp contacts, threaded coupling, and jam nut receptacle configuration make it a versatile choice for applications demanding secure, high-performance electrical connections across military, aerospace, and industrial sectors.
