Current Rating 13 A MIL DTL 38999 Series Ⅲ Crimp Contact Type Circular Connector Durable Electrical Connection Solutions. D38999/24WD05PN.TV07RW15-05PN.8D7-15W05PN

Product Description:

The MIL-DTL-38999 Series 3 connector, specifically designed with a Shell Size 15, is a high-performance connector widely recognized in military and aerospace applications. Known for its robustness and reliability, this connector is part of the Detailed-38999 Series Ⅲ family, which has been engineered to meet stringent military standards and demanding environmental conditions. The MIL-DTL-38999 Series 3 connectors are favored for their superior durability, excellent resistance to harsh environments, and outstanding electrical performance.

This particular MIL-DTL-38999 Series 3 connector features an Olive Green Cadmium shell finish, providing excellent corrosion resistance and long-lasting protection in challenging environments. The shell material is made from high-grade aluminum, which offers a lightweight yet strong structure that supports the overall durability and performance of the connector. The aluminum shell combined with the olive green cadmium plating ensures that the connector can withstand exposure to moisture, chemicals, and extreme temperatures, making it ideal for military and aerospace applications where reliability is critical.

Designed as a Jam Nut Receptacle, this connector type allows for secure mounting in panels or bulkheads, ensuring a stable and vibration-resistant connection. The jam nut design facilitates easy installation and removal while maintaining a tight and secure fit. This feature is particularly beneficial in applications where connectors may need to be replaced or serviced without compromising the integrity of the mounting surface. The connector’s jam nut receptacle configuration makes it versatile for various installations and adaptable to different equipment and systems.

Electrical performance is a key attribute of the MIL-DTL-38999 Series 3 connectors. With a current rating of 13 A, this connector supports the transmission of considerable electrical power, suitable for many military systems and communication devices. The 13-ampere current rating ensures that the connector can handle moderate to high electrical loads without overheating or performance degradation, making it reliable for critical applications. This current capacity, combined with the connector’s design, minimizes signal loss and maintains the integrity of the electrical connection under demanding conditions.

The MIL-DTL-38999 Series 3 connectors belong to the 8D Series, a subset of the Military Detail 38999 Series Ⅲ connectors, which are known for their high-density contact arrangements and rugged construction. The 8D Series connectors are designed to provide secure and efficient connections in compact spaces, making them ideal for modern military and aerospace equipment that require space-saving yet reliable interconnections. The 8D Series incorporates advanced sealing and shielding technologies to ensure protection against electromagnetic interference (EMI) and environmental contaminants.

As part of the Military Detail 38999 Series Ⅲ, the connector adheres to the MIL-DTL-38999 standards, which specify stringent requirements for environmental resistance, mechanical strength, and electrical performance. These standards ensure that the connector performs reliably under extreme conditions such as vibration, shock, temperature fluctuations, and exposure to moisture or dust. The Detailed-38999 Series Ⅲ connectors have become a benchmark for rugged, high-reliability connectors used in defense, aerospace, and other critical industries worldwide.

In summary, the MIL-DTL-38999 Series 3 connector with Shell Size 15, Olive Green Cadmium shell finish, aluminum shell material, jam nut receptacle configuration, and a current rating of 13 A is a premium choice for demanding military and aerospace applications. Its inclusion within the 8D Series of the Military Detail 38999 Series Ⅲ family underscores its advanced design, high performance, and reliability. Whether used in communication systems, avionics, or other mission-critical equipment, this connector delivers dependable electrical connections with excellent environmental resistance, ensuring operational integrity even in the most challenging environments.

Features:

• Product Name: MIL-DTL-38999 Series 3
• Also known as Military Detail-38999 Series Ⅲ, Military Detail 38999 Series Ⅲ, and Military-Detail 38999 Series Ⅲ
• Coupling Type: Threaded
• Operating Temperature Range: -55°C to +125°C
• Connector Type: Jam Nut Receptacle
• Contact Material: Copper Alloy
• Shell Material: Aluminum

Technical Parameters:

Applications:

The KAIDA MIL-DTL-38999 Series 3 connector, model number D38999/24WD05PN, is a high-performance product designed to meet the rigorous demands of military and aerospace applications. Originating from China, this connector is part of the renowned 8D Series, which is known for its durability, reliability, and superior electrical performance under extreme conditions. The Military-Detail 38999 Series Ⅲ connectors are specifically engineered to ensure secure and stable connections in critical environments.

The product features an Olive Green Cadmium shell finish that provides excellent corrosion resistance, making it ideal for use in harsh environmental conditions such as marine, desert, and extreme weather scenarios. The threaded coupling type ensures a robust and vibration-resistant connection, preventing accidental disconnections in high-vibration settings often encountered in military vehicles, aircraft, and ground equipment.

Constructed with a lightweight yet sturdy aluminum shell material, the connector balances strength and weight, crucial for applications where minimizing load is essential without compromising durability. The gold contact finish enhances conductivity and reduces the risk of oxidation, ensuring consistent and high-quality signal transmission, which is vital for mission-critical communication and control systems.

Designed to operate efficiently within a wide temperature range of -55°C to +125°C, the KAIDA MIL-DTL-38999 Series 3 connectors perform reliably in extreme cold and high-heat environments. This makes them suitable for deployment in a variety of military and aerospace scenarios, including fighter jets, helicopters, ground vehicles, and field communication systems, where temperature fluctuations are common and uncompromised performance is mandatory.

Overall, the KAIDA D38999/24WD05PN connector from the 8D Series with its Olive Green Cadmium finish and Military-Detail 38999 Series Ⅲ specifications is an optimal choice for applications demanding high resilience, superior electrical integrity, and dependable mechanical stability. It is extensively used in defense, aerospace, industrial, and other mission-critical sectors where connector failure is not an option.

Customization:

KAIDA offers customized Product Customization Services for the Military-Detailed 38999 Series Ⅲ connectors, specifically the D38999/24WD05PN model. This model, made in China, features 5 contacts with a shell size of 15. The shell finish is Olive Green Cadmium, providing durability and corrosion resistance suitable for demanding environments. The contact type is crimp, ensuring reliable electrical connections, and the coupling type is threaded for secure mating. Our Detailed-38999 Series Ⅲ customization services ensure that each connector meets stringent Military-Detail-38999 Series Ⅲ specifications, delivering high performance and reliability for your critical applications.

Support and Services:

Product Technical Support and Services for the MIL-DTL-38999 Series III connectors include comprehensive assistance to ensure optimal performance and reliability in demanding applications. Our support covers product selection guidance, technical data sheets, installation instructions, and troubleshooting resources. We provide expert consultation on connector configuration, environmental sealing, and compatibility with cable assemblies. Additionally, repair and maintenance services are available to extend the service life of your connectors. Training sessions and technical workshops can be arranged to equip your team with the necessary skills for handling and maintaining MIL-DTL-38999 Series III connectors. Our commitment is to deliver prompt and effective solutions tailored to meet the rigorous requirements of military and aerospace standards.

Packing and Shipping:

The MIL-DTL-38999 Series III connectors are packaged and shipped in a manner that ensures product integrity and protection against damage during transit. Each connector is individually packaged in a sealed plastic bag to prevent contamination and corrosion. The connectors are then placed in sturdy, appropriately sized boxes with cushioning materials to absorb shocks and vibrations.

For bulk orders, connectors are organized in trays or reels to facilitate handling and inventory management. All packaging materials comply with military standards for durability and environmental resistance.

Shipping is carried out with care to maintain the connectors' quality, using reliable carriers and tracking systems. The packaging is clearly labeled with product information, including part numbers, manufacturing dates, and lot codes, to ensure traceability and ease of identification upon receipt.

Special handling instructions, if applicable, are included to guide transportation and storage conditions, maintaining compliance with MIL-DTL-38999 specifications and ensuring optimal performance of the connectors upon installation.
