The MIL-DTL-38999 Series Ⅲ connector comes with 1 contact, making it suitable for low signal applications. This connector is available in shell sizes ranging from 11 to 81, providing a wide range of options to meet specific application requirements.
The MIL-DTL-38999 Series Ⅲ connector is commonly used in military and aerospace applications where reliability and durability are critical. This connector is designed to withstand harsh environmental conditions, including extreme temperatures, shock, and vibration.
The D38999/26WB81PN is a specific model within the MIL-DTL-38999 Series Ⅲ connector family. This model features a shell size of 81 and a threaded coupling type, making it suitable for high power applications. The D38999/26WB81PN also comes with 1 contact, making it ideal for low signal applications.
| Current Rating | 7 A |
| Contact Finish | Gold |
| Shell Finish | Olive Green Cadmium |
| Coupling Type | Threaded |
| Operating Temperature | -55°C To +125°C |
| Voltage Rating | 500V |
| Number of Contacts | 1 |
| Connector Type | Plug |
| Contact Material | Copper Alloy |
| Shell Size | 11-81 |
The olive green cadmium shell finish of this connector makes it suitable for use in military and aerospace applications where resistance to corrosion is critical. The MIL-DTL-38999 Series Ⅲ standard specifies the requirements for this type of connector, and KAIDA's product meets all the standard specifications.
The D38999 /26WB81PN model features a single contact, making it ideal for applications that require a single high-power signal or data transfer. The connector's voltage rating of 500V makes it suitable for use in power transmission applications.
This plug-type connector is designed to operate in a wide temperature range of -55°C to +125°C, making it suitable for applications that require high-temperature resistance. Its rugged construction also makes it suitable for use in harsh environments where vibration, shock, and extreme weather conditions may be present.
The KAIDA MIL-DTL-38999 Series Ⅲ connector is suitable for a wide range of applications, including military and aerospace, telecommunications, power transmission, and industrial control systems.
KAIDA offers product customization services for the Military-Detail-38999 Series Ⅲ connector model number D38999/26WB81PN. Originating from China, this threaded coupling type connector has a voltage rating of 500V and can operate within a wide temperature range of -55°C to +125°C. The contact finish is gold, and the connector type is a plug. Our customization services ensure that this connector meets your specific requirements and applications, making it the perfect fit for your project needs.
The MIL-DTL-38999 Series 3 circular connector is a high-performance, environmentally sealed connector designed for use in harsh environments. Our technical support team can provide assistance with connector selection, installation, and troubleshooting. We also offer a range of services including customized connector design, testing, and certification.
Product Packaging:
The MIL-DTL-38999 Series 3 product will be packaged in a sturdy cardboard box with suitable padding to prevent any damage during transit. The product will be sealed securely to prevent any tampering.
Shipping:
The product will be shipped via a reputable courier service that offers reliable and timely delivery. The shipping cost will be calculated based on the destination and weight of the package. The customer will be informed of the shipping cost and provided with a tracking number to track the package.
A: The Brand Name of this product is KAIDA.
2. Q: What is the Model Number of this product?A: The Model Number of this product is D38999 /26WB81PN.
3. Q: Where is this product made?A: This product is made in China.
4. Q: What is the shell size of this product?A: The shell size of this product is 26.
5. Q: What is the contact layout of this product?A: The contact layout of this product is WB81PN.
