This connector has a voltage rating of 500V, which makes it ideal for high voltage applications. It has a shell size ranging from 15 to 97, which makes it versatile and suitable for various applications. The shell size determines the connector's physical size and the number of contacts it can hold. This series offers a wide range of shell sizes to cater to different requirements.
The MIL-DTL-38999 Series Ⅲ features a threaded coupling type, which provides a secure and reliable connection. The threaded coupling type ensures that the connector will not disconnect accidentally, even in harsh environments where vibrations and shocks are common. This coupling type is widely used in military and aerospace applications because of its rugged design and durability.
The contact finish of the MIL-DTL-38999 Series Ⅲ is gold. Gold is an excellent conductor and provides a low contact resistance, which ensures that the connector has a stable and reliable connection. Gold is also resistant to corrosion and oxidation, which makes it ideal for use in harsh environments where the connector may be exposed to moisture or other corrosive agents. The gold contact finish enhances the connector's durability and performance, making it a popular choice for military and aerospace applications.
The MIL-DTL-38999 Series Ⅲ has a current rating of 7 A, which makes it suitable for low to medium power applications. The current rating is the maximum current that the connector can handle without overheating or degrading. The 7 A current rating makes this connector ideal for applications that require a medium amount of power, such as avionics, radar systems, and power distribution units.
In summary, the MIL-DTL-38999 Series Ⅲ is a rugged and reliable connector designed for use in harsh environments and extreme conditions. Its voltage rating of 500V, shell size ranging from 15 to 97, threaded coupling type, gold contact finish, and current rating of 7 A make it an excellent choice for military and aerospace applications. Its versatility and performance have made it a popular connector in various industries.
| Contact Material | Copper Alloy |
| Voltage Rating | 500V |
| Contact Type | Solder |
| Number of Contacts | 12 |
| Current Rating | 7 A |
| Shell Size | 15-97 |
| Connector Type | Receptacle |
| Operating Temperature | -55°C To +125°C |
| Contact Finish | Gold |
| Shell Finish | Stainless Steel Passivated (Military-Detailed 38999 Series Ⅲ) |
The MIL-DTL-38999 Series 3 is a versatile connector that can be used in a wide range of applications. It is commonly found in military and aerospace applications, where reliability and durability are of the utmost importance. The connector is designed to withstand harsh environments, including extreme temperatures, shock, and vibration. It is also resistant to corrosion, making it ideal for use in marine and offshore applications.
One of the key advantages of the MIL-DTL-38999 Series 3 connector is its versatility. It can be used in a wide range of applications, including avionics, defense systems, and commercial aircraft. It is also commonly used in communications systems, where it is used to transmit data and power. The connector is designed to provide a secure and reliable connection, even in the most demanding environments.
The MIL-DTL-38999 Series 3 connector is also ideal for use in industrial applications. It can be used in oil and gas exploration, as well as in mining and construction. The connector's rugged design and reliability make it ideal for use in these types of applications, where downtime can be costly.
In summary, the KAIDA MIL-DTL-38999 Series 3, or Detail-38999 Series Ⅲ, is a high-performance connector that is ideal for use in a wide range of applications. Its reliability, durability, and versatility make it a popular choice for military, aerospace, and industrial applications. If you are looking for a connector that can withstand harsh environments and provide a secure and reliable connection, the MIL-DTL-38999 Series 3 is an excellent choice.
Customize your KAIDA MIL-DTL-38999 Series 3 product with our product customization services. Our model number D38999/20KD97PN-H is manufactured in China and has a voltage rating of 500V. The shell finish is Stainless Steel Passivated and the coupling type is threaded. The contact type is solder and the contact material is copper alloy, ensuring the highest level of quality and durability.
Make your KAIDA MIL-DTL-38999 Series 3 product stand out with our customizable options. Our services include custom branding with the KAIDA logo, as well as modifications to the voltage rating, shell finish, coupling type, contact type, and contact material. Choose from a wide range of options to create a product that meets your specific needs.
Trust KAIDA to deliver Military-Detail 38999 Series III products that meet the highest standards of quality and performance. Contact us today to learn more about our customizable options and how we can help you create the perfect product for your application.
The MIL-DTL-38999 Series 3 product technical support and services include:
Product Name: MIL-DTL-38999 Series 3
Product Description: This product is a circular connector that is designed to meet military specifications. It is made with high-quality materials and is built to withstand harsh environmental conditions.
Package Contents:
Q: What is the brand name of the product?
A: The brand name of the product is KAIDA.
Q: What is the model number of the product?
A: The model number of the product is D38999/20KD97PN-H.
Q: Where is the product manufactured?
A: The product is manufactured in China.
Q: What is the series of the MIL-DTL-38999 product?
A: The series of the MIL-DTL-38999 product is Series 3.
Q: What is the type of connector for this product?
A: The type of connector for this product is a circular connector.
