The MIL-DTL-38999 Series 1 is a circular connector designed for use in harsh environments, with an operating temperature range of -55°C to +125°C. It is suitable for use in various military and aerospace applications where high performance and reliability are critical. This connector is manufactured to meet the stringent requirements of the military specification MS27505 and features an environmentally sealed design.
The connector type is circular, with a current rating of 7.5 A. It has an insert arrangement of 21-35, providing a wide range of configuration options for different applications. The mounting type for this connector is PCB, allowing for secure and stable installation on printed circuit boards.
The MIL-DTL-38999 Series 1 connector is constructed with electroless nickel plating, providing excellent resistance to corrosion and wear. This makes it suitable for use in harsh and demanding environments, ensuring long-term reliability and performance. Its environmentally sealed design also protects against moisture, dust, and other contaminants, making it ideal for use in rugged outdoor settings.
| Parameter | Value |
|---|---|
| Product Name | MIL-DTL-38999 Series Ⅰ |
| Part Number | MS27505E21F35SCN, MS27505E26F35SCN |
| Operating Temperature | -55°C To +125°C |
| Contact Material | Copper Alloy |
| Shell Size | 17 |
| Insert Arrangement | 21-35 |
| Number of Contacts | 79 |
| Contact Type | Short PCB Tail |
| Shell Finish | Electroless Nickel |
| Connector Type | Circular |
| Voltage Rating | 500V |
Brand Name: KAIDA
Model Number: MS27505E21F35SCN
Place of Origin: China
Mounting Type: PCB
Shell Finish: Electroless Nickel
Insert Arrangement: 21-35
Current Rating: 7.5 A
Connector Type: Circular
For those in need of a high-quality and reliable circular connector, KAIDA offers the perfect solution with our MS27505E21F35SCN model. This model, part of the MIL-DTL-38999 Series 1, is specifically designed for PCB mounting and boasts a current rating of 7.5 A. With its electroless nickel shell finish and 21-35 insert arrangement, the MS27505E21F35SCN is both durable and efficient.
At KAIDA, we understand the importance of customization and meeting the unique needs of our customers. That's why we offer a range of customization services for the MS27505E21F35SCN, such as custom branding and packaging options. Our team of experts is dedicated to providing top-of-the-line products and services to ensure customer satisfaction.
Choose KAIDA for your circular connector needs and experience the highest level of quality and customization. Contact us today to learn more about our products and services.
All MIL-DTL-38999 Series 1 products shall be packaged in accordance with the requirements of MIL-STD-2073-1, Class 3. The packaging materials used shall be suitable for protecting the products from damage during handling, storage, and transportation.
The products shall be packed in individual containers, such as plastic bags or antistatic tubes, to prevent any damage from moisture, dust, or electrostatic discharge. The containers shall be labeled with the product name, part number, quantity, and any other necessary information.
If multiple products are packed in a single container, they shall be separated by suitable materials to prevent any scratching or other damage during transportation.
The outer packaging, such as boxes or crates, shall be sturdy enough to withstand normal handling and transportation. The packaging shall be clearly marked with the product name, part number, quantity, and any special handling instructions.
All MIL-DTL-38999 Series 1 products shall be shipped in accordance with the requirements of MIL-STD-129, unless otherwise specified in the contract or purchase order.
The products shall be shipped by a reputable carrier, such as UPS, FedEx, or DHL, to ensure timely and safe delivery. The carrier shall be informed of any special handling or transportation requirements, such as temperature or humidity control, prior to shipping.
The shipping documents, including the packing list and bill of lading, shall be included with the shipment. The documents shall contain the product name, part number, quantity, and any other necessary information.
Upon receipt of the products, the customer shall inspect the packaging and products for any damage or discrepancies. Any issues shall be reported to the supplier immediately.
