Copper Alloy Contact MIL-DTL-38999 Series 2 6 Male Pins Mil Spec 38999

Part Number:MS27508E08B35PN

Product Description:

MIL-DTL-38999 Series Ⅱ is a MS27508 Box Mounting Receptacle connector, specifically designed for high-performance and high-reliability applications. This series utilizes a 6-contact configuration with 7.5 A current rating, and is constructed from copper alloy for superior strength and durability. It has a wide operating temperature range of -55 to 125°C, making it an ideal choice for applications where sustained temperature changes are likely. The MIL-DTL-38999 Series Ⅱ connector is reliable, and is designed to meet the stringent requirements of military and aerospace applications.

Features:

• Product Name: MIL-DTL-38999 Series Ⅱ
• Contact Plating: Gold
• Current Rating: 7.5 A
• Contact Material: Copper Alloy
• Insulator Material: Thermoplastic
• Series: MIL-DTL-38999 Series Ⅱ
• Olive green cadmium
• Box Mounting Receptacle
• Solder Termination

Technical Parameters:

Applications:

KAIDA MS27508E08B35PN is a MIL-DTL-38999 Series II connector designed for back panel mounting or box mounting receptacle. It features 6 contacts in crimp contact termination and Olive green cadmium finish. The contact material is made of copper alloy with a maximum current rating of 7.5A. It is perfectly suitable for harsh environment applications, like military and aerospace applications.

Customization:

• Brand Name: KAIDA
• Model Number: MS27508E08B35PN
• Place of Origin: China
• Current Rating: 7.5 A
• Contact Plating: Gold
• Shell Size: 08
• Operating Temperature: -55 To 125°C
• Contact Material: Copper Alloy

Support and Services:

MIL-DTL-38999 Series Ⅱ provides technical support and services, including the following:

• Design consulting
• Product installation and commissioning
• Product maintenance and repair
• Application support and troubleshooting
• Software updates
• Product warranty

Packing and Shipping:

Packaging and Shipping for MIL-DTL-38999 Series Ⅱ:

• Packaging should be done in accordance with the requirements of MIL-PRF-38999 Series Ⅱ.
• The package should be sealed with a sealant material.
• Packaging should be done in accordance with the requirements of MIL-STD-2073-1.
• Packaging should be done in accordance with the requirements of MIL-STD-2073-2.
• The product should be shipped in accordance with MIL-STD-129.
• The product should be shipped in accordance with MIL-STD-130.
• The product should be shipped in accordance with MIL-HDBK-119.

FAQ:

Q1: What is MIL-DTL-38999 Series Ⅱ? A1: MIL-DTL-38999 Series Ⅱ is a series of circular electrical connectors manufactured by KAIDA, with model number MS27508E08B35PN and made in China. Q2: What are the applications of MIL-DTL-38999 Series Ⅱ? A2: MIL-DTL-38999 Series Ⅱ connectors are used in aerospace and military applications, as well as in commercial and industrial applications. Q3: What features does MIL-DTL-38999 Series Ⅱ provide? A3: MIL-DTL-38999 Series Ⅱ connectors provide high reliability and performance in harsh environments. It provides a secure, rugged, and durable connection that resists shock, vibration, and extreme temperatures. Q4: What materials are used to make MIL-DTL-38999 Series Ⅱ? A4: MIL-DTL-38999 Series Ⅱ connectors are made of metal and plastic components, including stainless steel, aluminum, and PBT thermoplastic. Q5: What are the sizes available for MIL-DTL-38999 Series Ⅱ? A5: MIL-DTL-38999 Series Ⅱ are available in a variety of sizes ranging from 8 to 51 contacts. Contact sizes range from 20AWG to 10AWG.
