The MIL-DTL-83513 Micro-D Connectors are precision-engineered connectors designed to provide reliable and high-performance connections in a compact form factor. The specific product variant is identified by the part number CDBA-25TY+30CM.
These Micro-D connectors feature a contact material made of Copper Alloy, ensuring excellent conductivity and durability. With 25 contacts, this connector is suitable for applications requiring a moderate number of connections in a limited space.
The connectors are finished with Nickel plating, which not only enhances the appearance but also provides corrosion resistance and ensures a long service life. The Nickel plating adds to the durability of the connectors, making them suitable for demanding environments.
Constructed with a shell material of Aluminum, these connectors offer a lightweight yet sturdy housing for the internal components. The Aluminum shell provides protection and shielding for the contacts, maintaining signal integrity and reliability in various operating conditions.
Compliant with MIL Spec CDBA, these Micro-D connectors meet stringent military standards for quality, performance, and reliability. The CDBA series is known for its robust construction and high precision, making it ideal for mission-critical applications where dependable connections are essential.
| Part Number | CDBA-25TY+30CM |
| Number of Contacts | 25 |
| Mating Cycles | 500 |
| Voltage Rating | 500V |
| Shell Material | Aluminium |
| Contact Material | Copper Alloy |
| Gender | Microminiature Connectors |
| MIL Spec | CDBA |
| Finish | Nickel |
| Current Rating | 3A |
The MIL-DTL-83513 Micro-D Connectors by KAIDA (Model: CDBA-25TY+30CM) are versatile and reliable microminiature connectors originating from China. With a gender specification for Microminiature Connectors, these connectors boast 25 contacts, making them suitable for various applications.
These connectors, with the part number CDBA-25TY+30CM, adhere to the MIL Spec CDBA, ensuring high-quality performance in demanding environments. The Micro-D Metal Shell provides durability and protection, making them ideal for rugged applications.
The operating temperature range of -55 to +125°C allows these connectors to be used in extreme conditions without compromising functionality. The connectors are designed to withstand harsh temperatures, ensuring reliable performance in both hot and cold environments.
One of the key features of these connectors is the solder pot, which allows for secure and stable connections. The solder pot ensures a strong bond between the connector and the PCB, reducing the risk of signal loss or disconnection.
The CDBA Micro Rectangular Electrical Connector is suitable for a wide range of applications and scenarios. These connectors are commonly used in aerospace, military, and industrial applications where reliability and performance are crucial. They can also be found in communication equipment, medical devices, and test and measurement instruments.
Overall, the MIL-DTL-83513 Micro-D Connectors from KAIDA are a dependable choice for applications that require durable, high-performance connectors. Their robust design, wide operating temperature range, and solder pot feature make them ideal for various industries and environments.
Product Customization Services for the MIL-DTL-83513 Micro-D Connectors:
Brand Name: KAIDA
Model Number: CDBA-25TY+30CM
Place of Origin: China
Shell Material: Aluminium
Contact Plating: Gold Over Nickel
Number of Contact: 25
Operating Temperature: -55 To +125°C
Gender: Microminiature Connectors
Keywords: Micro Rectangular Electrical Connector, Solder pot
The MIL-DTL-83513 Micro-D Connectors product offers comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our dedicated team of experts is available to assist with any technical inquiries, troubleshooting, and product information needs. We are committed to providing reliable and efficient support services to help you maximize the benefits of our Micro-D Connectors.
Product Packaging and Shipping for MIL-DTL-83513 Micro-D Connectors:
The MIL-DTL-83513 Micro-D Connectors are carefully packaged to ensure their safe delivery to customers. Each connector is placed in a protective anti-static bag to prevent any damage during shipping. These bags are then placed in sturdy cardboard boxes with appropriate cushioning materials to further protect the connectors during transportation.
For shipping, we partner with reliable carriers to ensure timely and secure delivery of the MIL-DTL-83513 Micro-D Connectors to our customers. Each package is labeled with the necessary information for easy identification and tracking.
Q: What is the brand name of the Micro-D Connectors product?
A: The brand name is KAIDA.
Q: What is the model number of the Micro-D Connectors product?
A: The model number is CDBA-25TY+30CM.
Q: Where is the Micro-D Connectors product manufactured?
A: The product is manufactured in China.
Q: What is the pin count of the Micro-D Connectors product?
A: The pin count is 25.
Q: What is the length of the cable included with the Micro-D Connectors product?
A: The cable length is 30cm.
